Vol. 2 No. 3 (2026) Cover Image
Vol. 2 No. 3 (2026)

Published: September 30, 2026

Pages: 52-64

Research Article

Influence of Skirt Length and Foundation Size on the Bearing Capacity of Circular Foundations Resting on Sandy Soil

kawther yaly Hussain Al-Soudany 1 Nahla M. Salim 2 Luay Y. Hussein 1
1 College of Engineering, University of Technology-Baghdad, Baghdad, Iraq
2 Department of Civil Engineering, College of Engineering, Al-Naji University, Baghdad, Iraq
History
  • Received: June 14, 2026
  • Revised: September 13, 2026
  • Accepted: September 21, 2026
  • Available Online: September 30, 2026
DOI

https://doi.org/10.65505/ETES-26-0015

Abstract

Skirted foundations are an appropriate ground improvement method for improving the performance of shallow foundations built in sandy soils. This paper reports an experimental study on the effect of the skirt length and foundation size on the performance of circular foundations under vertical loading on medium-dense dry sand. Six laboratory model tests were made, of which two were unskirted and four skirted foundations. Two (2) different diameters of circular footings, 60 mm and 90 mm, were tested with two different lengths of the footing skirts (L/D), 0.5 and 1.0. Terzaghi's criterion, in which the settlement is 10% of the footing diameter, has been used to determine the ultimate bearing capacity. The results showed that the use of skirts was significantly helpful to improve the load–settlement response, increase the foundation stiffness, and increase the ultimate bearing capacity. The ultimate load for the footing of diameter 60 mm was increased from 0.167 kN to 0.304 kN, which is about 82% increase when the footing is skirted with L/D = 1.0. The same trend applied to the 90 mm diameter footing, where the ultimate load went from 0.343 kN to 0.677 kN, which is about 97% improvement. The bearing capacity of foundations with L/D = 0.5 increased by 29% and 43% for footing diameters of 60 mm and 90 mm, respectively. The experimental results also showed that as the skirt increased in length, the settlement decreased, and the failure mechanisms were more stable and deeper due to the increased soil confinement and passive resistance along the walls of the skirts. Further, all skirts yielded higher failure loads with larger foundation diameters. The study has verified that the length of skirts and foundation size are important parameters that control the performance of circular skirted foundations on sandy soils. The application of skirts is an effective and cost-efficient way to increase bearing capacities, decrease settlement, and enhance shallow foundation stability.

Keywords

References

  1. S. Gourvenec and M. F. Randolph, “Consolidation beneath circular skirted foundations,” Int. J. Geomech., vol. 10, no. 1, pp. 22–29, 2010. https://doi.org/10.1061/(ASCE)1532-3641(2010)10:1(22)
  2. J. A. Schneider and M. Senders, “Foundation design: A comparison of oil and gas platforms with offshore wind turbines,” Mar. Technol. Soc. J., vol. 44, no. 1, pp. 32–51, 2010. https://doi.org/10.4031/MTSJ.44.1.5
  3. S. Tripathy, “Load carrying capacity of skirted foundation on sand,” Ph.D. dissertation, National Institute of Technology, Rourkela, India, 2013.
  4. M. R. Mahmood, M. Y. Fattah, and A. Khalaf, “Experimental study on bearing capacity of skirted foundations on dry gypseous soil,” Int. J. Civ. Eng. Technol., vol. 9, no. 10, pp. 1910–1922, 2018.
  5. S. Parmar and R. Patel, “Bearing capacity of isolated square skirted foundation on cohesionless soil: An experimental and analytical study,” J. Adv. Geotech. Eng., vol. 4, no. 2, pp. 1–11, 2021.
  6. S. P. Singh, S. Kumar, and S. Sarkar, “Numerical analysis of skirted foundation on sand for load–displacement behaviour,” in Proc. Indian Geotech. Conf. 2022, vol. 2. Singapore: Springer Nature Singapore, 2024, pp. 251–263. https://doi.org/10.1007/978-981-97-1741-5_22
  7. K. Terzaghi, Theoretical Soil Mechanics. New York, NY, USA: John Wiley & Sons, 1943.
  8. A. J. Lutenegger and M. T. Adams, “Bearing capacity of footings on compacted sand,” in Proc. Int. Conf. Case Histories Geotech. Eng., St. Louis, MO, USA, Mar. 9–12, 1998, pp. 1216–1224.
  9. A. B. Cerato, “Scale effect of shallow foundation bearing capacity on granular material,” Ph.D. dissertation, Dept. Civil Environ. Eng., Univ. Massachusetts Amherst, Amherst, MA, USA, 2005.
  10. ASTM D422-63, Standard Test Method for Particle-Size Analysis of Soils. West Conshohocken, PA, USA: ASTM International, 2006.
  11. ASTM D854-23, Standard Test Methods for Specific Gravity of Soil Solids by the Water Displacement Method. West Conshohocken, PA, USA: ASTM International, 2006.
  12. ASTM D3080-04, Standard Test Method for Direct Shear Test of Soils Under Consolidated Drained Conditions. West Conshohocken, PA, USA: ASTM International, 2006.
  13. ASTM D2049-69, Standard Test Method for Relative Density of Cohesionless Soils. West Conshohocken, PA, USA: ASTM International, 1969.
  14. ASTM D4254-16, Standard Test Methods for Minimum Index Density and Unit Weight of Soils and Calculation of Relative Density. West Conshohocken, PA, USA: ASTM International, 2006.
  15. A. Z. El-Wakil, “Horizontal capacity of skirted circular shallow footings on sand,” Alex. Eng. J., vol. 49, no. 4, pp. 379–385, 2010. https://doi.org/10.1016/j.aej.2010.07.003
